2.5 LED Definitions
1.PSU_LED1
PSU_ALERT_N
LED
Pin
Signal
+
VCC3_AUX
-
N881139857
State
Description
OFF
OFF
PSU status is normal
ON
Red
PSU status is abnormal
2.CAT_LED1
ERR_LED1
RESET_LED
Pin
Signal
+
VCC3
-
CAT_LED_C/CPU_EER2_BMC_N
State
Description
OFF
OFF
CPU NO ERROR
ON
RED
CPU occur Error
3.ID_LED1
ID LED
Pin
Signal
+
VCC3_AUX
-
Rear_ID_LED_N
State
Description
OFF
OFF
System no command
ON
Blue
System confirm
4.SYS_RST_LED1
System Reset
LED
Pin
Signal
+
VCC3_AUX
-
N860685946
State
Description
OFF
OFF
System off
ON
Green
System Power OK
5.BMC_LED1
BMC Heart
Beat LED
Pin
Signal
+
VCC3_AUX
-
N877897845
State
Description
OFF
OFF
The LED shuts off when the BMC
controller cannot be detected or
properly initiated.
Blinking
Green
The LED blinks per second to
indicate that the BMC controller is
working normally
6.IPMI_LED1
On board BMC
IPMI ALERT LED
Pin
Signal
+
VCC3_AUX
-
BMC_HW_FAULT_N
State
Description
OFF
OFF
HW Sensor status is normal
ON
Red
HW Sensor status is abnormal.
7.P0_PG_LED1
CPU Power
Good LED
Pin
Signal
+
VCC3
-
N877269560
State
Description
OFF
OFF
CPU Power Good Fail
ON
Green
CPU Power Good OK
