1. Rear ID LED Button (IDLED_BTN1)
18. SATA DOM Connector (SATA 3.0 signals)
7Pin+2Power (SATADOM1)
2. VGA+ COM PORT (VGA_COM1)
19. Mini SAS HD Connector (sSATA 0_3)
3. RJ45+USB3.0 x 2 (USB3_IPMI_LAN1)
20. SATA DOM Power (DOM_PWR2)
4. 80P OCULINK Connector (J21)
21. SATA DOM Power (DOM_PWR1)
5.Reset Button (RST_BTN1)
22. 4-pin FAN Connector (SYS_FAN_4)
6. 80P OCULINK Connector (J20)
23. 4-pin FAN Connector (SYS_FAN_3)
7. IPMB Connector (IPMB_HD1)
24. 8-pin Power Connector (PW2)
25. Mini SAS HD Connector (SATA 4_7)
9. System FAN Connector (J29)
26. Mini SAS HD Connector (SATA 0_3)
10. Front Panel Connector (FPIO_1)
27. 4-pin FAN Connector (SYS_FAN_2)
11. TYAN Module Header (DBG_HD1)
28. 4-pin FAN Connector (CPU_FAN)
12. SGPIO Header (SSATA_SGPIO1)
29. 4-pin FAN Connector (SYS_FAN_1)
13. Clear Button (CLEAR_BTN1)
30. PSMI Connector (PSIMI1)
31. 24-pin Power Connector (PW1)
15. SATA DOM Connector(SATA 3.0 signals)
7Pin+2Power (SATADOM2)
32. 4-pin FAN Connector (SYS_FAN_5)
16. Vertical Type A USB Connector
(TYPEA_USB1)
33. 4-pin FAN Connector (SYS_FAN_6)
17. FPB USB2.0/USB3.0 *2 Header
(USB3_FPIO1)
a. NVDIA GPU Card Select Jumper (3PHD8)
f. LPC /Espi Select Jumper (3PHD5)
b. PSU Throttling Function Jumper (3PHD9)
g. Chassis Intrusion Header (INTRUDER_HD1)
c. LPC /Espi Select Jumper (3PHD4)
h. ME Recover Jumper (3PHD3)
d. BMC COM2/COM5 Select Jumper (3PHD6)
i. ME Debug Header (3PHD2)
e. BMC COM2/COM5 Select Jumper (3PHD7)
j. PCH IE Debug Header (3PHD1)
k. CPU VR SCLK/SDAT Header (J10)
I PSU Alert LED (PSU_LED1
VI BMC Heartbeat LED (BMC_LED1)
VII PWR_GOOD_LED (PCH_PWOK_LED1)
III CPU_ERROR LED (CAT_LED1)
VIII On board BMC IPMI ALERT LED
(IPMI_LED1)
IX CPU0 Power LED (P0_PG_LED1)
V SYS_RESET_ LED (SYS_RST_LED1)
