Expansion Slots
PCI-E
(1) PCI-E Gen3 x16 slot
Others:
(1) PCI-E Gen3 x8 OCP 2.0 slots
(con.A+con.B)
LAN
Port Q'ty
(1) PHY
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) Mini-SAS HD (8-
ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
sSATA
Connector
(2) 8-pin SATA/SATA-
DOM, (1) Mini-SAS
HD (4-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input /Output
USB
(5) USB3.0 ports (2 at rear, 2 via
cable, Type-A)
COM
(1) DB-9 COM Connector (at
rear, COM1) + (1) Header
(COM2)
VGA
(1) D-Sub 15-pin VGA port (at
rear)
RJ-45
(1) GbE port dedicated for IPMI
Audio
Line-in, Line-out, Mic-in,
Surround, Side surround,
CEN/LFE at rear
Front Panel
(1) 2x12-pin SSI front panel
header
SATA
(2) 8-pin SATA/SATA-DOM
connectors + (3) Mini-SAS HD
(4-in-1) connectors
