7
Operating Environment
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158°
F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL
support lists.
Package Contains
Motherboard
(1) S5630 Motherboard
Manual
(1) Web User's manual, (1)
Quick Installation Guide
Installation CD
(1) TYAN installation CD
S5630GMRE Specifications
Processor
Socket Type / Q'ty
LGA3647/ (1)
Supported CPU
Series
Intel Xeon Scalable Processor
Family
Thermal Design
Power (TDP)
wattage
Max up to 205W
Chipset
PCH
Intel C621
Memory
Supported DIMM
Qty
(12) DIMM slots
DIMM Type /
Speed
DDR4 RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 384GB RDIMM/ 768GB
LRDIMM/ 1,536GB RDIMM
3DS/LRDIMM 3DS *Follow latest
Intel DDR4 Memory POR
Memory channel
6 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x16 slot
Others:
(1) PCI-E Gen3 x8 OCP 2.0 slots
