SATA 80P OCULINK Connector (OCUL1/ OCUL2)
Signal
Pin
Pin
Signal
GND1
A1
B1
GND15
SATA0_RXP
A2
B2
SATA0_TXP
SATA0_RXN
A3
B3
SATA0_TXN
GND2
A4
B4
GND16
SATA1_RXP
A5
B5
SATA1_TXP
SATA1_RXN
A6
B6
SATA1_TXN
GND3
A7
B7
GND17
A8
A8
B8
B8
J2A9_WAKEA#_SDOUTA
A9
B9
B9
GND4
A10
B10
GND18
NVME3_PEREFCLK_DN
A11
B11
J2B11_PERSTA#_SDINA
NVME3_PEREFCLK_DP
A12
B12
B12
GND5
A13
B13
GND19
SATA2_RXP
A14
B14
SATA2_TXP
SATA2_RXN
A15
B15
SATA2_TXN
GND6
A16
B16
GND20
SATA3_RXP
A17
B17
SATA3_TXP
SATA3_RXN
A18
B18
SATA3_TXN
GND7
A19
B19
GND21
A20
A20
B20
B20
A21
A21
B21
B21
GND8
A22
B22
GND22
SATA4_RXP
A23
B23
SATA4_TXP
SATA4_RXN
A24
B24
SATA4_TXN
GND9
A25
B25
GND23
SATA5_RXP
A26
B26
SATA5_TXP
SATA5_RXN
A27
B27
SATA5_TXN
GND10
A28
B28
GND24
A29
A29
B29
B29
J2A30_WAKEB#_SDOUTB
A30
B30
B30
GND11
A31
B31
GND25
A32
A32
B32
J2B32_PERSTB#_SDINB
A33
A33
B33
B33
GND12
A34
B34
GND26
SATA6_RXP
A35
B35
SATA6_TXP
SATA6_RXN
A36
B36
SATA6_TXN
GND13
A37
B37
GND27
SATA7_RXP
A38
B38
SATA7_TXP
SATA7_RXN
A39
B39
SATA7_TXN
GND14
A40
B40
GND28
