TYAN S8026 - Installing the Memory

http://www.tyan.com
33
2.9 Installing the Memory
Before installing memory, ensure that the memory you have is compatible with the
motherboard and processor. Check the TYAN Web site at http://www.tyan.com for
details of the type of memory recommended for your motherboard.
 Support (16)DDR4 288-pin DIMM slots,
 Support (8) memory channels per CPU
 Support (2) DIMM slots per CPU channel
 RDIMM /LRDIMM/ NVDIMM DDR4 2667Mhz w/ECC
 Up to 1024 GB RDIMM/LRDIMM
