TYAN S8026 - Motherboard Components

http://www.tyan.com
15
Motherboard Components
Connectors
1. RJ45+USB3.0 x 2 (LAN1)
19. Front Fan_3 (SYS_FAN_3)
2. SGPIO Header (SGPIO0)
20. PCIE/SATA 80P OCULINK Connector
(OCUL2)
3. VGA+COM Port (VGA_COM1)
21. PCIE/SATA 80P OCULINK Connector
(OCUL1)
4. SGPIO Header (SGPIO1)
22.Front FAN_2 (SYS_FAN_2)
5. BroadCom BCM5720 LAN Connector (LAN2)
23.Front FAN_1 (SYS_FAN_1)
6. BMC SPI Socket (BMC_SOCKET1)
24.CPU_FAN (CPU_FAN)
7. BroadCom BCM5720 LAN Connector (LAN3)
25.System Fan Connector (FAN_HD1)
8. BIOS SPI Socket (BMC_SOCKET1)
26. Front Panel Header (FPIO_2)
9. Rear ID LED Button(ID LED_BTN1)
27.PSMI Header (PSMI_HD1)
10. Rear FAN_2 (SYS_FAN_5)
28.IPMB Header(IPMB1)
11. Rear FAN_1 (SYS_FAN_4)
29. 8-pin Power Connector(PW3)
12. COM2 Header (COM2)
30. 8-pin Power Connector(PW2)
13. NGFF 22x80mm Connector (NGFF2)
31. ATX Power Connector(24p)(PW1)
14. Vertical Type A USB Connector (TYPEA_USB1)
32.Reset Button(COLD_RST_BTN1)
15. NGFF 22x80mm Connector (NGFF1)
33.Power Button(PWR_BTN1)
16. SATADOM Connector (SATA3.0 signals)
7Pin+_2Power (SATADOM2)
34 NMI Button (NMI_BTN)
17. SATADOM Connector (SATA 3.0 signals)
7Pin+2Power (SATADOM1)
35. TYAN Module Header (DBG_HD1)
18. FPB USB2.0/USB3.0*2 Header (USB3_FPIO1)
Jumpers
a. CMOS Clear Jumper (J194)
e. OCP CONN MUX & PRSENT select
Jumper (3PHD11)
b. BMC COM PORT2(RX) Jumper (J190)
f. System Reset Jumper (J192)
c. BMC COM PORT2(TX) Jumper (J191)
g. J1 NVMe or SATA select Jumper
(JP9_1/3)
d. PC BEEP Jumper (J120)
h. J2 NVMe or SATA select Jumper
(JP9_2/4)
PCIE Slots
A PCIE3.0 Slot x24 (PESLOT1)
C. OCP A Slot (OCP1_A)
B. PCIE3.0 Slot x24 (PESLOT2)
D. OCP A Slot (OCP1_B)
LEDs
i FPGA_CRC_ERROR LED (LED1)
vii NGFF1_LED(LED_M1)
ii FPGA_NSTATUS LED (LED2)
viii NGFF2_LED(LED_M2)
iii FPGA_CONF_ DONE LED (LED3)
ix HDD_ACT_LED(HDD_LED3)
iv P0_PROCHOT_ LED (LED4)
x On Board BMC IPMI ALERT(IPMI_LED2)
v PWR_GOOD_ LED (LED5)
xi PSU_Alert_N LED(PSMI_LED1)
vi Reset_ LED (LED7)
xii BMC Hearbeat LED(BMC_HBLED)
