Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S8026 motherboard, based on the
Aspeed
®
AST2500 chipset. The S8026 is designed to support AMD
®
Zen
®
Naples
series Processor, and Up to 1,024GB RDIMM/LRDIMM DDR4 2667 MHz memory.
Leveraging advanced technology from Intel
®
, the S8026 is capable of offering
scalable 32 and 64-bit computing, high-bandwidth memory design, and lightning-
fast PCI-E bus implementation.
The S8026 not only empowers you in today‟s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S8026 with the power and flexibility to meet demanding
requirements for today‟s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S8026GM2NRE Specifications
Processor
Socket Type / Q'ty
AMD Socket SP3/ (1)
Supported CPU Series
(1) AMD EPYC™ 7000 Series
Processor
Average CPU Power
(ACP) wattage
Max up to 180W
Memory
Supported DIMM Qty
(16) DIMM slots
DIMM Type / Speed
DDR4 ECC
RDIMM/LRDIMM/NVDIMM 2667
Capacity
Up to 1,024GB RDIMM/LRDIMM
Memory channel
8 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x 24 slot, (1) PCI-E
Gen3 x 24 slot (w/x16 link; can be
x24 link if OCP mezz. conn.B is not
used. Please contact with Tyan
technical support for details.)
Recommended TYAN
Riser Card
M7106-L24-3F, PCI-E x16 slot 2U
riser card (left), M7106-L24-3F, PCI-E
