TYAN S8026 - Page 5

http://www.tyan.com
5
x16 slot 2U riser card (right)
Others:
(1) PCI-E Gen3 x16 OCP 2.0 slots
(conn.A+conn.B)
LAN
Port Q'ty
(2) GbE ports + (1) dedicated for IPMI
Controller
Broadcom BCM5720
PHY
Realtek RTL8211E
Storage
M.2 connector
(2) M.2 connectors
(22110/2280/2260/2242) by PCI-E &
SATA interface
NVMe
(6) PCI-E x8 SFF-8612 OCuLink
connectors for (12) NVMe ports, (2)
PCI-E x8 SFF-8612 OCuLink
connectors for (4) NVMe/ (16) SATA
ports
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.0 ports (at rear), (2) USB
2.0 ports (via cable), (1) Type-A
USB3.0 port
COM
(1) DB-9 COM Connector (at rear,
COM1) + (1) Header (COM2)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports, (1) Dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
Power
SSI 24-pin + 8-pin + 8-pin power
connectors
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Fan fail LED indicator, Over
temperature warning indicator, Fan &
PSU fail LED indicator
Others
Watchdog timer support
Server Management
AST2500 iKVM Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and remote
platform-flash, USB 2.0 virtual hub
AST2500 IPMI Feature
24-bit high quality video compression,
10/100/1000 Mb/s MAC interface
