Recommended Memory Population Table (Single CPU)
CPU Installed
Quantity of
memory installed
2
4
6
8
10
12
14
16
P0_D0_Umc0_Ch_D1
√
√
√
√
√
√
√
√
P0_D0_Umc0_Ch_D0
√
√
√
√
P0_D0_Umc1_Ch_C1
√
√
√
√
√
√
√
P0_D0_Umc1_Ch_C0
√
√
√
√
P0_D1_Umc1_Ch_B1
√
√
√
√
√
√
P0_D1_Umc1_Ch_B0
√
√
√
√
P0_D1_Umc0_Ch_A1
√
√
√
√
√
P0_D1_Umc0_Ch_A0
√
√
√
√
P0_D3_Umc0_CH_E0
√
√
√
√
P0_D3_Umc0_CH_E1
√
√
√
√
√
P0_D3_Umc1_CH_F0
√
√
√
P0_D3_Umc1_CH_F1
√
√
√
√
√
P0_D2_Umc1_CH_G0
√
√
P0_D2_Umc1_CH_G1
√
√
√
√
√
P0_D2_Umc0_CH_H0
√
P0_D2_Umc0_CH_H1
√
√
√
√
√
NOTE:
1.√ indicates a populated DIMM slot.
2. Use paired memory installation for max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
4. Dual-rank DIMMs are recommended over single-rank DIMMs.
5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if
populating only a single DIMM per channel.
6. Always install with CPU0 Socket and DIMM_0 Slot first, following the alphabetical order.
