LED7
RESET_LE
D
Pin
Signal
+
VDD_33_DUAL
-
N20422896
State
Description
OFF
OFF
The LED shuts off when
the BMC controller
cannot be detected or
properly initiated.
ON
ORG
The LED lights up when
BMC was reset OK;
LED_M1
NGFF1_LE
D
Pin
Signal
+
VDD_33_RUN
-
NGFF1_LED_L
State
Description
OFF
OFF
The LED shuts off when
no NGFF1 SSD insert
ON
Green
The LED lights up when
detect the NGFF1 SSD;
LED_M2
NGFF2_LE
D
Pin
Signal
+
VDD_33_RUN
-
NGFF2_LED_L
State
Description
OFF
OFF
The LED shuts off when
no NGFF2 SSD insert
ON
Green
The LED lights up when
detect the NGFF2 SSD;
HDD_LED3
HDD_ACT_
LED
Pin
Signal
+
VDD_33_RUN
-
HDD_ACT_LED_N
State
Description
OFF
OFF
NGFF Active LED off
ON
Green
NGFF Active LED on
IPMI_LED2
On board BMC
IPMI ALERT
LED
Pin
Signal
+
VDD_33_DUAL
-
BMC_HW_FAULT_N
State
Description
OFF
OFF
HW Sensor status is
normal
ON
Red
HW Sensor status is
abnormal.
PSMI_LED1
PSU_ALERT_
N LED
Pin
Signal
+
VDD_33_DUAL
-
N18825566
State
Description
OFF
OFF
PSU status is abnormal
ON
ON
PSU status is normal
