8
COM1) + (1) Header (COM2)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports, (1) Dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
Power
SSI 24-pin + 8-pin + 8-pin power
connectors
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Fan fail LED indicator, Over
temperature warning indicator, Fan &
PSU fail LED indicator
Others
Watchdog timer support
Server Management
AST2500 iKVM
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and remote
platform-flash, USB 2.0 virtual hub
AST2500 IPMI Feature
24-bit high quality video compression,
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, Boot from USB
device/PXE via LAN/Storage, User
Configurable FAN PWM Duty Cycle,
Console Redirection, ACPI 6.1,
SMBIOS 3.1/PnP/Wake on LAN, ACPI
sleeping states S5
Physical Dimension
Form Factor
EATX
Board Dimension
12"x13" (305x330mm)
Operating System
OS supported list
Please refer to our AVL support lists.
Regulation
FCC (DoC)
Class A
CE (DoC)
Yes
Operating Environment
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant
Yes
Package Contains
Motherboard
(1) S8026 Motherboard
