117
DRAM ECS Count Mode
0: RowCount Mode 1: CodeWord Mode 0xFF: Auto – ABL decides default as
CodeWord Mode
Row Count Mode / Code Word Count Mode / Auto
DRAM AutoEcs during Self Refresh
0: AutoEcs Disabled 1: AutoEcs Enabled 0xFF: Auto – ABL choose
AutoEcs Disabled
AutoEcs Disabled / AutoEcs Enabled / Auto
DRAM ECS WriteBack Suppression
To enable/Disable ECS Error Correction Writeback suppression
0: ECS Writeback Suppression Disabled
1: ECS Writeback Suppression Enabled
0xFF: Auto – ABL chooses Writeback Suppression to be Enabled by default
Disabled / Enabled / Auto
DRAM x4 WriteBack Suppression
To enable/Disable X4 device Error Correction Writeback suppression
0: ECS Writeback Suppression Disabled
1: ECS Writeback Suppression Enabled
0xFF: Auto – ABL chooses Writeback Suppression to be Enabled by default
Disabled / Enabled / Auto
