Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S8050 motherboard, based on the
Aspeed
®
AST2600 chipset. The S8050 is designed to support AMD
®
EPYC™ 9004
Series Processor, and up to 2,048GB RDIMM / 3DS RDIMM DDR5 4800 memory.
Leveraging advanced technology from AMD
®
, the S8050 is capable of offering
scalable 32 and 64-bit computing, high-bandwidth memory design, and lightning-
fast PCI-E bus implementation.
The S8050 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S8050 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S8050GM2NE Specifications
Processor
Q'ty / Socket Type (1) AMD Socket SP5
Supported CPU Series (1) AMD EPYC™ 9004 Series Processor
Thermal Design Power
Wattage
Max up to 400W (cTDP)
Memory
Supported DIMM Qty (8) DIMM slots
DIMM Type / Speed RDDR5 4800 w/ ECC (1.1V) when 1DPC
3DS RDDR5 4800 w/ ECC (1.1V) when 1DPC
Capacity Up to 2,048GB RDIMM / 3DS RDIMM DDR5 4800
Memory channel 8 Channels per CPU
Memory voltage 1.1V
Expansion Slots
PCIe (5) PCIe Gen.5 x16 slot
LAN
Q'ty / Port (2) GbE ports + (1) GbE dedicated for IPMI
Controller Intel I210-AT
PHY Realtek RTL8211F
Storage SATA
Connector (12) SATA
Controller Direct from AMD EPYC CPU
Speed 6Gb/s
RAID N/A
