TYAN S8050 - Page 5

http://www.tyan.com
5
Storage NVMe
Connector (M.2) (2) 22110/2280 (by PCIe Gen.4 interface)
Connector (U.2) (2) MCIO x4 / (2) MCIO x8
Graphic VGA
Connector type D-Sub 15-pin
Resolution Up to 1920X1080 @60Hz
Chipset Aspeed AST2600
Input /Output
NVMe (2) MCIO x4 / (2) MCIO x8
USB (2) USB3.2 Gen.1 ports (@ front) /
(1) USB3.2 Gen.1 conn ( Type-A ) /
(2) USB3.2 Gen.1 ports (@ rear)
COM (1) DB-9 COM Connector
VGA (1) D-Sub 15-pin port
RJ-45 (2) GbE ports + (1) GbE dedicated for IPMI
Front Panel (1) 2x12-pin SSI front panel header
SATA (2) Mini-SAS HD (SFF-8643) connectors /
(4) 7-pin SATA connectors
Power (2) 2x4 Power input connectors /
(1) 2x12 Power input connectors
Others (1) ID button
TPM (Optional)
TPM Support Please refer to our TPM supported list.
Interface SPI
System
Monitoring
Chipset Aspeed AST2600
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
Voltage Monitors voltage for CPU, memory, chipset & power
supply
LED Fan fail LED indicator / Over temperature warning
indicator
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2600
AST2600 iKVM Feature 24-bit high quality video compression / Supports
storage over IP and remote platform-flash / USB 2.0
virtual hub
AST2600 IPMI Feature IPMI 2.0 compliant baseboard management
controller (BMC) / 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 256MB
Feature Hardware Monitor / FAN speed control automatic /
Boot from USB device/PXE via LAN/Storage /
Console Redirection / SMBIOS 3.0/PnP/Wake on LAN
/ ACPI sleeping states S0, S5
Physical
Dimension
Form Factor CEB
Board Dimension 12” x 10.5” (305 x 267mm)
