TYAN S8050 - Software and OS Compatibility

http://www.tyan.com
8
System
Monitoring
Chipset Aspeed AST2600
Fan Total (6) 4-pin headers
Temperature Monitors temperature for CPU & system
environment
Voltage Monitors voltage for CPU, memory, chipset & power
supply
LED Fan fail LED indicator / Over temperature warning
indicator
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2600
AST2600 iKVM Feature 24-bit high quality video compression / Supports
storage over IP and remote platform-flash / USB 2.0
virtual hub
AST2600 IPMI Feature IPMI 2.0 compliant baseboard management
controller (BMC) / 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 256MB
Feature Hardware Monitor / FAN speed control automatic /
Boot from USB device/PXE via LAN/Storage /
Console Redirection / SMBIOS 3.0/PnP/Wake on LAN
/ ACPI sleeping states S0, S5
Physical
Dimension
Form Factor CEB
Board Dimension 12” x 10.5” (305 x 267mm)
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
C-Tick Class A
VCCI Class A
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant Yes
Operating
System
OS supported list Please refer to our AVL support lists.
Package
Contains
Motherboard (1) S8050 Motherboard
Manual (1) Quick Installation Guide
I/O Shield (1) I/O Shield
Cable SATA (2) SATA signal cables

1.3 Software Specifications
For the latest AST2600 User’s Guide and OS (operation system) support, please
visit the Tyan’s Web site at http://www.tyan.com for the latest information
