TYAN S8050 - Page 135

http://www.tyan.com
135
Configure IPV4 support
Management Port 1
Configuration Address Source
Select the configure LAN channel parameters statically or dynamically (by BIOS or
BMC). Unspecified option will not modify any BMC network parameters during BIOS
phase.
Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp
Management Port 2
Enable/Disable BMC Share NIC
Disabled / Enabled
NOTE: When Management Port 2 is set to Enabled, the following items will be
available to set up.
Configuration Address Source
Select the configure LAN channel parameters statically or dynamically (by BIOS or
BMC). Unspecified option will not modify any BMC network parameters during BIOS
phase.
Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp
Configure IPV6 support
Management Port 1
IPV6 Support
Enable or Disable LAN1 IPV6 Support
Disabled / Enabled
Management Port 2
IPV6 Support
Enable or Disable LAN2 IPV6 Support
Disabled / Enabled
NOTE: When Management Port 2 is set to Enabled, the following items will be
available to set up.
Configuration Address Source
Select the configure LAN channel parameters statically or dynamically (by BIOS or
BMC). Unspecified option will not modify any BMC network parameters during BIOS
phase.
Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp
