14
Jumpers & Connectors
Connectors
1. IPMB Connector (IPMB1) 26. 4-pin Fan Connector (SYS_FAN_2)
2. Front Fan Header(FAN_HD1) 27. M.2 Connector (CN1) PCIE only
3. COM2 Port Header(COM2) 28. MCIOx4 SATA/NVME (CN10)
4. TYAN Module Header(J62) 29. 4-pin Fan Connector (SYS_FAN_1)
5. TYPE A USB3.2 Gen1
Header(TYPEA_USB1)
30. 7p SATA Connector (J15)
6. NMI Button (SW5) 31. 7p SATA Connector (J16)
7. USB3.2 Gen1 Header (USB3_FPIO1) 32. 7p SATA Connector (J18)
8. COLD RST Button (SW2) 33. 7p SATA Connector (J19)
9. SGPIO0 Header (SGPIO0)
34. MCIOx4 SATA/NVME (CN11)
10. PWR Button (SW1)
35. MCIOx8 NVME (CN6)
11. HDT Header(J1)
36. MCIOx8 NVME (CN5)
12. WARM_RST Button (SW12)
37. PSMI Header (PSMI_HD1)
13. I210 LAN LED Header (J29)
38. SVI Header (J17)
14. Front Panel Header (FPIO_2) 39. 4-pin Fan Connector (CPU0_FAN)
15. HDD BP Smbus Header(HDR_2) 40. 4-pin Fan Connector (SYS_FAN_5)
16. HDD BP Smbus Header(HDR_1) 41. VGA Header (VGA1)
17. Intrusion Header(J66) 42. ID Button (ID_BTN)
18. CPLD JTAG Header (J12)
43. CPU and Memory Power Connector
(PW3)
19. M.2 Connector (CN3)PCIE Only 44. IPMI LAN USB3.0 Connector (LAN5)
20. Mini SAS Connector (J26)
45. VGA and COM1 Port Header
(VGA_COM1)
21. Mini SAS Connector (J25) 46. RJ45 LAN Port (LAN3/LAN4)
22. Power Connector (PW1) 47. RJ45 LAN Port (LAN1)
23. CPU and Memory Power Connector (PW2) 48. RJ45 LAN Port (LAN2)
24. 4-pin Fan Connector (SYS_FAN_4) 49. BIOS Debug (BIOS_DBG1)
25. 4-pin Fan Connector (SYS_FAN_3) 50. SPI TPM Connector (J56)
Slots
A. PCIE#3 x16 (PESLOT3) D. PCIE#2 x16 (PESLOT2)
B. PCIE#5 x16 (PESLOT5) E. PCIE#1 x16 (PESLOT1)
C. PCIE#4 x16 (PESLOT4)
Jumpers
a. COM2 Switch Jumper(J6) f. BMC Header (J2)
b. COM2 Switch Jumper (J7) g. CPLD PowerOn Jumper (J3)
c. RESET Switch Jumper (J33) h. VRM SMBUS SEL Jumper (3PHD1)
