25
+ VDD_33_DUAL
- HDD_ACT_LED_ALL_L
State Description
OFF OFF HDD non-activity
ON Blue HDD activity
2. D52
PWR_GOOD
LED
Pin Signal
+ VDD_5_DUAL
- P0_PWR_GOOD_LED-
State Description
OFF OFF Power Off
ON Green System Power Good
3. D57 PWROK LED
Pin Signal
+ VDD_5_DUAL
- P0_PWROK_LED-
State Description
OFF OFF CPU Power Off
ON Green CPU Power OK
4. D58
CPU RESET
LED
Pin Signal
+ VDD_5_RUN
- P0_RESET_LED_L
State Description
OFF OFF CPU Reset Normal
ON RED CPU Reset Not Send Out
5. D26 PROCHOT LED
Pin Signal
+ VDD_33_DUAL
- BMC_P0_PROCHOT_N
State Description
OFF OFF Normal
ON RED
SYSTEM PROCHOT OR BMC NOT
ready
6. D31
PSU_ALERT
LED
Pin Signal
+ VDD_33_DUAL
- PSMI_PSU_ALERT_LED_L
State Description
OFF OFF Normal
ON RED PSU_ALERT
7. D32
SYS_PWROK
LED
Pin Signal
+ VDD_33_DUAL
- SCM_SYS_PWROK-
State Description
