Stop Bits
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning). The standard setting is 1 stop bit. Communication with slow devices
may require more than 1 stop bit.
1 / 2
Flow Control
Flow Control can prevent data loss from buffer overflow. When sending data, if the
receiving buffers are full, a ‘stop’ signal can be sent to stop the data flow. Once the
buffers are empty, a ‘start’ signal can be sent to re-start the flow. Hardware flow
control uses two wires to send start/stop signals.
None / Hardware RTS/CTS
VT-UTF8 Combo Key Support
Enable VT-UTF8 Combination Key Support for ANSI/VT100 terminals.
Enabled / Disabled
Recorder Mode
With this mode enabled only text will be sent. This is to capture Terminal data.
Disabled / Enabled
Resolution 100x31
Enable or disable extended terminal resolution.
Disabled / Enabled
Putty KeyPad
Select FunctionKey and KeyPad on Putty.
VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400
