TYAN TIGER 100 - Software Specifications

S1832DL Tiger 100
7
INTRO
Physical Dimensions •ATX design.
•12 inches x 9.8 inches.
•Requires Intel Venus compatible I/O
shield.
BIOS Information •AMI Plug and Play flash BIOS.
•Deep Green, Energy Star, ACPI,
Year 2000, and PC98 compliant.
•Soft power-down, multiple boot
options.
•Win98/NT5 ready, DMI 2.0
compliant.
•PCI 2.1, APM 1.1 compliant.
Disk Drive & System I/O •Two PCI bus mastering EIDE
channels.
•Supports EIDE CD-ROMs.
•PIO Mode 3 & 4 (up to 17MB/sec
DTR).
•UltraDMA/33 bus mastering mode
(up to 33MB/sec DTR).
•Support for two floppy drives (up to
2.88MB).
•Two serial ports (16550 UARTs).
•One ECP/EPP parallel port.
•One Serial IR (InfraRed) I/O interface port.
•Two USB rev 1.2 (universal serial
bus) connectors.
•One PS/2 mouse connector.
•One PS/2 keyboard connector.
Software Specifications
OS •Operates with MS-DOS, Windows
3.x, Windows for WorkGroups 3.x,
Windows 95, Windows 98, Windows
NT, OS/2, Novell Netware, and SCO Unix.
