Tyco DN150 Quick Start Guide

TFP1321
Page 12 of 18
Nominal
Valve
Size
ANSI
Inches
(DN)
Inches
(mm)
A B C D E F G H J
1 1/2
(40)
2.8
(71)
9.7
(246)
10.4
(264)
12.7
(323)
16.2
(412)
7.3
(185)
10.2
(259)
8.02
(204)
1.2
(31)
2
(50)
2.8
(71)
9.7
(246)
10.4
(264)
12.7
(323)
16.2
(412)
7.3
(185)
10.2
(259)
8.09
(205)
2.9
(74)
3
(80)
3.0
(76)
10.9
(277)
12.0
(305)
12.6
(320)
17.9
(455)
5.8
(147)
13.8
(351)
3.79
(96)
3.6
(91)
4
(100)
3.0
(76)
12.2
(310)
13.1
(333)
14.1
(358)
19.6
(498)
5.1
(129)
16.8
(427)
4.54
(115)
4.3
(109)
6
3
(150)
4.5
(114)
13.6
(345)
15.0
(381)
16.4
(417 )
22.3
(566)
3.4
(86)
22.4
(569)
5.83
(148)
5.7
(145)
8
(200)
5.3
(135)
16.3
(414)
17. 2
(437)
19.5
(495)
27. 5
(699)
2.9
(74)
27. 5
(699)
5.24
(133)
6.7
(170)
NOTES
1. Dimensions based on drain valves being open.
2. Dimensions do not provide installation clearance.
3. Also applicable to metric 165,1 mm size.
H
F
E
DCB
J
A
G
FIGURE 7
DV-5
a VALVE
DELUGE ELECTRIC ACTUATION TRIM ASSEMBLY
NOMINAL DIMENSIONS
