Diagnostic Test
The following sequence of events occur during a diagnostic test:
A. The detector performs a link quality test.
Note: The detector must be in local or diagnostic mode to perform the link quality test.
In diagnostic mode, if you press the test button for more than 6 seconds, an alarm
message is sent to the panel and a Temporal-3 alarm signal is sounded. After this
sequence is completed, the panel responds by sending an “Alarm in Memory” message
to the device.
B. At the end of the diagnostic test the LED blinks three times. The following table indicates
the received signal strength.
LED
Response
Green LED
blinks
Orange LED
blinks
Red LED
blinks
No blinks
Reception
Strong Good Poor
Paired, no
communicaton
IMPORTANT!Reliable reception must be confirmed. Therefore, "poor" signal strength is not
acceptable. If you receive a "poor" signal from the device, re-locate it and re-test until a "good"
or "strong" signal strength is received. For UL/CUL installations, the test results must be "strong".
See the alarm systems installation guide for detailed diagnostic tests.
Owner’s Maintenance
The smoke detector is designed to require minimum maintenance. If the case becomes dusty,
vacuum with a small brush attachment. If the case is greasy, wipe the case gently with a soft
cloth slightly dampened with soapy water.
Never disassemble the smoke detector; there are no user serviceable parts inside the unit.
You may only remove detector from backplate to replace batteries if not serviced by
installer. When replacing the batteries, follow the instructions specified in the Installation
Instructions.
Never paint the unit. Paint may prevent smoke from entering the unit. If you are planning
renovations or repainting, take precautions to avoid dust, paint or chemical contamination
to the detector.
If the unit is located in an area where it is exposed to high levels of dust or insects and causes
false alarms, it may require service; contact your smoke detector installer or dealer.
Testing and maintenance procedures shall be in accordance with CAN/ULC-S552-14.
Specifications
l
Regulatory listings: UL268/ULC-S529 PG9936
l
Diameter: 5 in (125 mm)
l
Height: 2.5 in (63 mm)
l
Weight (including battery): 8.75 oz (243 g)
l
Color: White
l
Spacing rating: 70 ft (21.3 m)
l
Alarm sensitivity (threshold) PG9936 (cULus): 2.64 - 3.50 %/ foot obscuration
l
Alarm sensitivity (threshold) PG4936 / PG8936: complies with EN14604
l
Audible signal (ANSI Temporal 3): 85 dBA minimum in alarm
l
Operating temperature: PG9936 40 ºF - 100 ºF (4.4 ºC - 37.8 ºC)
l
Operating temperature with heat detector: 32 ºF - 100 ºF (0 ºC - 37.8 ºC)
l
Operating temperature for smoke alarm:PG4936 41 ºF - 113 ºF (5 ºC - 45 ºC); Type A
Photoelectric Smoke Alarm (Australia)
l
Heat alarm: 135 ºF (57 ºC);
l
Humidity: 15 % - 90 % RH, non-condensing
l
Approved batteries: EN: 3 AAA, Duracell MN2400.
UL: 3 AAA, Energizer E92 or Duracell Procell PC2400.
UL: 3 AAA, Energizer E92 or Duracell Procell PC2400.
l
Battery life expectancy: 3 years
l
Alarm silencing: PG4936 8 minutes automatically resettable
l
Supervisory transmission frequency: PG4936 / PG8936 128 second intervals
l
Maximum Tx power: 868.0 MHz - 868.6 MHz: 14 mW/11.46 dBm, 868.7 MHz - 869.2 MHz:
14 mW/11.46 dBm
l
Low battery detection: Low battery 14 days remaining
l
Modulation: GFSK
l
Country of origin: Made in the USA
Limited Warranty
Digital Security Controls warrants that for a period of twelve months from the date of purchase, the product shall be free of
defects in materials and workmanship under normal use and that in fulfillment of any breach of such warranty, Digital Security
Controls shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot. This
warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damage
due to causes beyond the control of Digital Security Controls such as lightning, excessive voltage, mechanical shock, water
damage, or damage arising out of abuse, alteration or improper application of the equipment.
The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties,
whether expressed or implied and of all other obligations or liabilities on the part of Digital Security Controls. Digital Security
Controls neither assumes responsibility nor authorizes any other person purporting to act on its behalf to modify or to change
this warranty, nor to assume for it any other warranty or liability concerning this product.
