Tyco DV-5 Quick Start Guide

Page 14 of 14
TFP1420
TYCO FIRE PRODUCTS, 451 North Cannon Avenue, Lansdale, Pennsylvania 19446
DELUGE VALVE (SELECT ONE)
P/N’s are for American Standard Groove x Groove Connections, and Threaded Ports, For
other configurations refer to Technical Data Sheet TFP1305. Specify: (size) Model DV-5
groove x groove Deluge Valve, P/N (specify).
1-1/2 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-919
2 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-910
3 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-912
4 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-913
6 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-915
8 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-477-1-916
RISER CHECK VALVE (SELECT ONE)
P/N’s are for American Standard Grooved Connections. For other configurations refer to
Technical Data Sheet TFP950 for the groove x groove Model CV-1FR Riser Check Valve.
Specify: (size), Model CV-1FR groove x groove Riser Check Valve, P/N (specify).
For 1-1/2
inch risers, use the 2 Inch Riser Check Valve.
2 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 59-590-1-020
3Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 59-590-1-030
4 Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 59-590-1-040
6Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 59-590-1-060
8Inch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 59-590-1-080
COUPLING (SELECT ONE)
P/N’s are for American Standard Grooved Connections. For other configurations and
finishes refer to Technical Data Sheet TFP1830 or TFP1880. A coupling to attach the
Riser Check Valve to the outlet of the Deluge Valve must be separately ordered. Specify:
(Size), (Figure #), painted, (description), P/N (specify).
For 1-1/2 inch risers, order an
additional Reducing Coupling for the outlet of the 2 inch Riser Check Valve.
2 x 1-1/2 Inch Figure 716 Painted Reducing Coupling.. ... ... ... ... ... ... ... P/N 7162015ES
2 Inch Figure 772 Painted Rigid Coupling .. ... ... ... ... ... ... ... ... ... ... P/N 77220ASC
3 Inch Figure 772 Painted Rigid Coupling .. ... ... ... ... ... ... ... ... ... ... P/N 77230ASC
4 Inch Figure 772 Painted Rigid Coupling .. ... ... ... ... ... ... ... ... ... ... P/N 77240ASC
6 Inch Figure 772 Painted Rigid Coupling .. ... ... ... ... ... ... ... ... ... ... P/N 77260ASC
8 Inch Figure 772 Painted Rigid Coupling .. ... ... ... ... ... ... ... ... ... ... P/N 77280ASC
PREACTION TRIM (SELECT ONE)
Specify: (specify size and finish — galvanized is standard) Semi-Preassembled Super-
vised Single Interlock Preaction System With Electric Actuation Trim for Model DV-5
Deluge Valves, P/N (specify).
1-1/2 & 2 Inch Galvanized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-2-119
1-1/2 & 2 Inch Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-1-119
3 Inch Galvanized. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-2-116
3 Inch Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-1-116
4, 6 & 8 Inch Galvanized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-2-113
4, 6 & 8 Inch Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-478-1-113
SUPERVISORY AIR SUPPLY (SELECT ONE)
A device capable of maintaining a nominal system air or nitrogen pressure of nominal 10
psi (0,69 bar) must be separately ordered. Specify: (Specify model and description), P/N
(specify).
Model AMD-1 Air Maintenance Device (TFP1221) . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-324-2-002
Model AMD-3 Nitrogen Maintenance Device (TFP1241) . . . . . . . . . . . . . . . . . . . . P/N 52-328-2-001
Model G16AC812 Automatic Supervisory Air Supply (TD126) . . . . . . . . . . . . . . . . P/N 52-150-1-001
SOLENOID VALVE (SELECT ONE)
A Solenoid Valve compatible with the anticipated maximum water supply pressure must
be ordered separately. Refer to Technical Data Sheet TFP2180 for other voltage ratings
and NEMA classifications. Specify: 24 VDC, NEMA 2, 4, and 4X, (specify 175 or 250 psi)
Solenoid Valve, P/N (specify).
175 psi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-287-1-024
250 psi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-287-1-124
ACCESSORIES (AS NEEDED)
Specify: (description), PN (specify).
600 PSI Water Pressure Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 92-343-1-004
Model WMA-1 Water Motor Alarm (TFP921) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 52-630-1-001
TABLE A — ORDERING LIST

Tyco DV-5 Specifications

General

Brand	Tyco
Model	DV-5
Category	Control Unit
Language	English
