Specifications and Requirements
Specifications
iSTAR Ultra G2 Specifications
Environmental
Operational Temperature 32° F (0° C) to 120° F (49° C)
Electrical (GCM)
Electrical Input 12 VDC or 24 VDC (4.5 A)
Electrical (ACM)
Vreader
Electrical Input Up to 12 VDC or 24 VDC (12.5 A)
Vlock 1
Electrical Input Up to 12 VDC or 24 VDC (12.5 A)
Vlock 2
Electrical Input Up to 12 VDC or 24 VDC (12.5 A)
RS485/Wiegand/Aux
Electrical Output 12 VDC (1.5 A) per reader.
Relay Ports (Dry - Primary and Secondary)
Electrical Output
Primary: 12 - 24 VDC (5 A)
Secondary: 12 - 24 VDC (1 A)
Relay Ports (Wet - Primary and Secondary)
Electrical Output
Primary: 12 - 24 VDC +/- 15% (0.75 A)
Secondary: 12 - 24 VDC +/- 15% (0.75 A)
Table 1:Environmental and Electrical Specifications
NOTE
Voltage tolerances are 85% - 100%of listed specifications.
