12. Specifications
GENERAL
Detector type Special two-channel PIR outputs
OPTICAL
Lens data Mirror type, common parabolic-elliptic surface
Detector mirror max.
coverage
Up to 8 m or 26.2 ft/6°
Detection ranges Select 3 m, 5 m or 8 m. Alternatively, select 9.8 ft, 16.4 ft, or 26.3 ft. See Table 4.
Sensitivity The minimum difference between the temperature of the ambient background and a person is 3°C at 0.3 m/s.
ELECTRICAL
Power supply Type C
Internal battery Two 3 V lithium battery, type CR-123A.
Note:For UL installations, use Panasonic and GP only.
Nominal battery
capacity
1450 mAh
Battery life (typical
use)
Minimum: 1 year
Typical use: 3 years
Note: The measurement of battery life with typical use is not verified by UL.
Low battery threshold 4 V
Battery power test The power supply is type C in accordance with EN50131-6 Documentation - Clause 6.
The battery power test is performed when the batteries are first inserted and periodically every several hours.
Current consumption Quiescent average: 30 μA
Maximum during transmission: 150 mA
FUNCTIONAL
Alarm period 2 seconds
Pet immunity Up to 18 kg (40 lb)
Pet configurations l Setting 1: Pet < 18 kg or 40 lbs (default)
l Setting 2: Small pet < 3 kg or 6.6 lb or rodents
l Setting 3:No function
l Setting 4: No pet
WIRELESS
Frequency Europe and rest of world: 433-434 MHz, 868-869 MHz
USA and Canada: 912-919 MHz
Note:Only devices in frequency band 915 MHz are UL/ULC listed.
Max Tx power 10 dBm @ 433 MHz, 14 dBm @ 868 MHz
Communication
protocol:
PowerG
Supervision Signals at 256 second intervals.
Tamper alert Reports when a tamper event occurs and following any subsequent messages until the tamper switch is restored.
MOUNTING
Mounting type: Wall mounting
Mounting height: 1.6 - 2 m (5.25 - 6.56 ft)
Horizontal adjustment: -90° to +90° in 10° steps
ENVIRONMENTAL
RF immunity 20 V/m up to 1000 MHz, 10 V/m up to 2700 MHz
Operating
temperatures
- 35°C to 60°C (-31°F to 140°F)
Note:For UL/ULC installation, the operating temperature has been evaluated up to 66°C.
Humidity Average relative humidity of up to approximately 75% non-condensing. For 30 days per year the relative humidity may vary
between 85% and 95% non-condensing.
For UL installations: 5% to 93% with no condensation
Storage temperatures -35°C to 60°C (-31°F to 140°F)
PHYSICAL
Size (diameter) 145 mm x 71 mm x 62 mm (5.7 in. x 2.8 in. x 2.45 in.)
Weight (with battery) 283 g (10 oz)
Color White
D-307164 MP-902 PG2 Installation instructions 8
