3.13 SERVICE
Press 7 from the Main menu. The following type of screen
will be displayed:
3.13.1 WALK TEST
When selected, this option allows single or multiple points
to be tested without an alarm being raised.
Press 1 from the Service menu.
Only one Walk Test session can be active at one time.
Select the required option:
Use the ‘>>’, ‘-’ and ‘+’ keys to select the required
options. The Panel number is only displayed when it is
part of a networked system.
1 - Walk Test
2 - Maintenance
3 - Diagnostics
MX Panel
Thu, 26-May-09
00:01
Company Name
General
Back
Service
4 - Calibrate DDM800
5 - Restart System
6 - Switches
Panel : 01
Area : All
Type : Input
Loop : All
Mode : MANUAL
Multisensor : Part
MX Panel
Wed, 09-Mar-08
00:01
Company Name
General
Back
Walk test
>> + - Start
Depending on the selected settings, the display will
change. The following screen is an example of ‘Area’
selected as ‘Point’.
To start the Walk Test press F5.
Possible Settings
Panel
The selection of panel is only available for panels that are
in a networked system.
Area
Type
Loop
Only with Area as ‘All’ or ‘Zone’.
Walk Test of all loops or of a specific loop (A, B, C, D, E,
F, G or H).
• All Walk Test of all elements of a special type.
(Selection in the field ‘Type’ eg, callpoints).
• Zone Walk Test of all elements of a specific type
in a specific zone.
• Point Walk Test of the input of a single point.
• Input Walk Test of all inputs.
• Detectors Walk Test of detectors.
• Alarm I/Ps Walk Test of default inputs covered by
supergroup ‘Fire Alarm Inputs SG’.
• Call Points Walk Test of call points.
• Sounders Walk Test of sounders by loop or all
loops plus FIM sounders.
Panel : 01
Area : Point
Type : Input
Location : Loop
Zone : 01
Point : 01
Mode : MANUAL
Multisensor : Part
MX Panel
Thu, 26-Jul-07
00:01
Company Name
General
Back
Walk test
>> + - Start
To Next Page
