Tyco QRS User Manual

TFP110 0
Page 10 of 16
Nominal
Valve
Size
ANSI
Inches
(DN)
Inches
(mm)
A B C D E F G H J
1-1/2
(40)
2.8
(71)
9.7
(246)
10.4
(264)
15.7
(399)
16.2
(412)
7.3
(185)
10.2
(259)
8.0
(203)
1.2
(31)
2
(50)
2.8
(71)
9.7
(246)
10.4
(264)
15.7
(399)
16.2
(412)
7.3
(185)
10.2
(259)
3.8
(97)
2.9
(74)
3
(80)
3.0
(76)
10.9
(277)
12.0
(305)
16.3
(414)
18.5
(470)
5.8
(147)
13.8
(351)
3.9
(99)
3.6
(91)
4
(100)
3.0
(76)
12.2
(310)
13.1
(333)
16.5
(419)
21.0
(533)
5.1
(129)
16.8
(427)
4.5
(114)
4.3
(109)
6
(150)
4.5
(114)
13.6
(345)
15.0
(381)
18.4
(467)
24.8
(630)
3.4
(86)
22.4
(569)
5.9
(150)
5.7
(145)
8
(200)
5.3
(135)
16.3
(414)
17. 2
(437)
19.5
(495)
29.1
(739)
2.9
(74)
27. 5
(699)
5.2
(132)
6.7
(170)
Notes:
1. Dimensions are based on drain valves being open.
2. Dimensions do not provide installation clearance.
H
F
E
DCB
J
A
G
FIGURE 4B
DV-5a VALVE - DOUBLE INTERLOCK PREACTION ELECTRIC/ELECTRIC ACUATION TRIM
WITH MODEL QRS ELECTRONIC ACCELERATOR OPTIONAL COMPONENTS
INSTALLATION DIMENSIONS
