6. T1204 Motherboard (C1626) Features
Figure 8 illustrates the C1626 motherboard features referred to elsewhere in the documentation.
Figure 8 – C1626 motherboard layout
Notes:
I. “Evacuate” or “Evac” = Manual Fire Alarm/Muster.
II. The 16-pin Microcontroller programming header is for use during manufacturing only and should not have
any links fitted across any of the pins. Improper use of the connector may result in permanent damage to
the motherboard.
Remote Inputs:
Silence Alarms
Evac
Reset
Zone
Detection
Inputs
J1
Display
Connector
Configuration
switches
SW1/1 to SW1/10
FS1
Battery Fuse
Battery
Terminals
Battery
Thermistor
Terminals
Power Supply LED
Status
indicators:
OUTPUT OK
Battery/Charger Fault
Charger Fault
Mains Fault
Secondary AC from
transformer
(when fitted)
Aux DC
Supply
24V & 0V
Repeater
Terminals:
A, B, GND
–
Not Used
Reset
Relay
Output
J19 DC supply in
and PSU faults from
PS40 PSU [when
fitted]
Aux Outputs:
Dis
ablement
A
ctive
Evac
uate Active
Buzzer
Active
Fire Output
[Marked Fire
Routing]
Fault Output
[Marked
Fault
Routing]
Fire
Protection
Output
J2 and J23.
Connector
s for
C1665 Muster
Interface
– Not
Used
Alarm Circuits
[Marked with
Active
Polarity
]
Zone
Outputs
1
-4
Configuration
mode enabled
LED indicator
Configuration
switches
SW2/1 to SW2/10
J18
Earth Fault
Disable
Link
Connections
for Repeater
Interface. Not
Used
Configuration links
for Fire & Fault
Signal [Routing]
O/Ps and Fire
Protection O/P
Microcontroller
Programming
Connector
–
Factory
Use
Only
