Tyco T1232R-C User Manual

T1200
MARINEC-P-A
3 02/14
PAGE 56 of 67
20. Mechanical, Electrical and Environmental Specification
Mechanical
Specification
Panel
Repeater
T1204
DC
T1204
A1
T1204
A2
T1216-C T1232-C T1200B-C T1216R-C T1232R-C
Size (mm)
Height
Width
Depth
270
335
148
270
335
148
270
335
148
See
Figure 2
See
Figure 2
235
395
106
See
Figure 2
See
Figure 2
Weight
excluding
batteries (kg)
7.1 8.3 8.4 8.1 9.3 4.4 6.7 7.7
Mains Input
Specification
T1204A1
T1204A2
T1204DC
T1216-C
T1232-C
110V
AC
PSU
230V
AC
PSU
24V
DC
PSU
110/230V
AC
PSU
110/230V
AC
PSU
Maximum Input
Power (W)
110 115 70 200 200
Protection
[Warning: Replace
only with identical
type & rating of
BEAB or VDE
approved fuse]
T3.15A
H250V
[3.15A anti-surge]
T3.15A
H250V
[3.15A anti-surge]
T3.15A
H250V
[3.15A anti-surge]
T5A
H250V
[5A anti-surge]
T5A
H250V
[5A anti-surge]
Voltage
93.5 – 121Vac
195.5 – 253Vac
18 – 31.2Vdc
93.5 – 253Vac
93.5 – 253Vac
Frequency
(Hz)
47.5 – 63 47.5 – 63 N/A 47.5 – 63 47.5 – 63
Cable requirements
Minimum of 1mm
2
c.s.a. copper protected by a 5A fuse.
Power Supply
Output
Specification
T1204A1 T1204A2 T1204DC T1216-C T1232-C
Maximum Short
Term Current
Output
(I max b) (A)
1.5 1.5 1.5 4 4
Maximum
Continuous
Current
(I max a) (A)
0.6 0.6 0.6 2 2
Minimum Output
Current
(I min) (mA)
N/A
(PSU is integrated into the motherboard)
30 30 30
Voltage Output,
Mains On (Vdc)
27.3 (Nominal, dependent on temperature)
Maximum Current
Output, Mains
Failed (A)
1.5 1.5 1.5 4 4
Voltage Output
(Vdc)
28.6 – 20.0 28.6 – 20.0 28.6 – 20.0 28.6 – 20.0 28.6 – 20.0
Max Ripple [full
load/battery
disconnected]
(mV p-p)
200 200 200 300 300
Output voltage
adjustment
Factory set
Output protection
Electronic current limiting
Common fault
output
Outputs not available to user – internally connected to panel PSU monitor.
Mains failed fault
output
Outputs not available to user – internally connected to panel PSU monitor.
