Battery Specification T1204A1 T1204A2 T1204DC T1216-C T1232-C
Battery charger output:
Temperature compensated
float charger
28.15V
±
0.1V@ -10
°
C
26.6V
±
0.1V@ +55
°
C
(A)
1.5 1.5 1.5 5 5
Maximum internal
resistance of battery &
charger circuit:
(Ri max) (Ω)
1 1 0.6 0.6 0.6
Battery type:
POWERSONIC
Warning: Replace only
with identical battery
2 off PS-1230 or PS1270 [12V 3.4Ah or 7Ah]
In a T1200B battery box
2 off PS-12170 [12V 17Ah]
In a T1200B-C battery box
Battery capacity
24 hours stand-by + 0.5 hours alarm
Battery size (mm):
[For one 12V pack]
L
HT
H
W
PS-1230
PS-1270
PS-1230
PS-1270
PS-1230
PS-1270
PS-1230 PS-1270
L
W
H
HT
133mm
67mm
60mm
66mm
151mm
65mm
94mm
98mm
Battery Dimensions ± 2mm
77
.0 ±
2181.5 ± 2
167
.5 ±
2
126
.0 ±
2
PS-
12170 PS-
12170
PS-
12170
Battery circuit protection:
Warning: Replace only
with identical type & rating
of fuse
F2AL250V
20mm fast
blow glass fuse
F2AL250V
20mm fast blow
glass fuse
T8AH250V
20mm Ceramic
Fuse
T8AH250V
20mm Ceramic
Fuse
T8AH250V
20mm Ceramic
Fuse
Mains failed fault battery
current (mA)
55 55 70 125 170
Mains failed alarm battery
current (mA)
90 90 105 170 210
