RX-812 COARSE SIEVE SHAKER PARTS LIST
ITEM PART DESCRIPTION QTY.
1 LC10016 Locating Pin 1
2 LC10017 Clamping Knobs 2
3 LC10018 Clamp Bar 1
4 LC10015 Clamping Rods 2
5 P-1500-23 Motor ¼ HP 115/230V 60/50 Hz 1 Phase 1
6 R-10112 Flexible Conduit Connector 2
7 102542 Oilite Flexible Conduit – 8-1/2” 1
8 ZA10956 10-24 Cup Point Set Screw 4
9 LC10014 Coupling 2
10 LB10266 Rolok 10-24 Self Tap Screw 6
11 LC10007 Shield 1
12 LB10041 Special Carriage Bolt 1
13 LC10005 Bearing Ring 2
14 LC10052 Adapter 1
15 R-40040 Timer Mounting Clip 2
16 R-40029 Electronic Timer (115v) 1
16 R-40037 Electronic Timer 230v) 1
17 ZZ10792 -28 x 1-3/4” Soc. Cap. Ser. 2
18 LC10003 Base, Sieve Shaker 1
19 LC10052 Rubber Channel 1
20 ZF10183 3/8” – 16 x 1.00 Hex Hd. Bolt 3
21 108184 Nameplate 1
22 LB10111 Drive Pulley – 1-1/2” O.D. 1
23 ZA10148 10-24 x 3/8” Cup Point Set Scr. 1
24 LB10451 Pulley/Eccentric Assembly 1
25 LB10191 Flanged Stand Off Bushing 1
26 LC10006 Carrying Plate 1
27 ZF10168 3/8” Hard Washer 1
28 ZF10221 3/8” -16 Lock Nut 1
29 LB10201 Stand Off Bushing 2
30 LB10211 Drive Belt-21.310 1
31 ZZ10801 ¼-“28 Black Lock Not 2
32 ZZ10301 Flat Washer 6
33 ZF10184 5/16”-18 Black Hex Hd. Bolt 2
34 LC10010 12” Cover Clamping Plate 1
35 LC10011 8” Cover Clamping Plate 1
36 LC10009 12” to 8” Conversion Plate 1
37* R-10018 110V Cord Set 1
38 LC10012 Arm 1
To Next Page
