Tyler Ro-Tap RX-29-E - Parts List

5
RX-29 & RX-30 Ro-Tap
®
PARTS LIST
ITE
M
PART DESCRIPTION QTY
REQ’D
ITEM PART DESCRIPTION QTY
REQ’D
1 107770 Base 1 41 R-40037 Electronic Timer (230v) 1
2 R-20029 Hammer 1 41A R-40040 Timer Mounting Clip 2
3 R-20023 Hammer Block 1 42 P-1500-
23
Motor-Standard 115/230v 60/50Hz
1Phase
1
4 R-30019 Sheet Guard 1 42A ZF10183 3/8-16 x 1” Hex Flange Bolt 4
5 R-30010 Rotating Guard 1 43 R-10058 Timing Belt 1
6 R-10036 Lift Rod 2 44 R-10055 Shim 1
7 R-10038 Upper Main Shaft Washer 1 45 ZZ10068 1//2-13 x 2.50” Long Hex Hd. Bolt 1
8 R-20027 Main Shaft 1 45A ZZ10323 ½ I.D. Lock Washer 1
9 R-30008 Upper Carrying Plate/RX-29 1 1
9a R-30008-1 Upper Carrying Plate (alum) 1 47 R-10079 Clamp Screw 2
9 R-30027 Upper Carrying Plate/RX-30 1 48 ZF10221 3/8” Lock Nut 3
10 R-30009 Lower Carrying Plate 1 49 ZF10222 1/2” Hex Lock Nut 1
12 R-20039 Cam Gear 1 50 ZF10231 10-32x.50” LongFlatHeadSocketCap
Screw
3
13 R-30015 Timing Belt Pulley 1 51 ZF10241 3/8-16x.75”LongFlatHeadSocketCap
Screw
2
14 R-10034 Eccentric Disc 2 51A ZF10183 3/8-16x1” Hex Flange Bolt 2
15 R-10032 Block 1 52 114162 3/6-16x x 62” Long Hex Head Screw 2
16 R-30007 Sieve Cover (RX-29) 1 53 ZF10251 5/16-24x1.25” LongSocket
HeadCapScrew
1
16 R-30011 Sieve Cover (RX-30) 1 54 R-20082 Adj. Handle (Support Bar) 2
17 R-30006 Sieve Support Plate (RX-29) 1 55 ZA10148 #10-24x.25” Socket Hd. Set Screw 1
17 R-30013 Sieve Support Plate (RX-30) 1 56 ZF10271 3/8 I.D. X 1.50” O.D. Fender Washer 1
18 R-30023 Sieve Support Clamp Bar (RX-29) 1 60* R-10018 Timer Cord w/Plug 1
18 R-30022 Sieve Support Clamp Bar (RX-30) 1 61* R-10019 Cable Tie Ml’g 3
19 R-20019 Backup Plate 1 62* R-10112 Straight Connector (APC-050) 2
20 R-20020 Bearing Plate 1 66* 107764 Flexible Conduit 1
21 R-20033 Shield 2 67* R-10076 Wire Clip 1
22 R-10028 Tube Spacer 2 68* ZZ10011 Screw For Wire Clip & Ground Screw 3
23 R-10029 Cam Shoulder Screw 1 69* R-20081 Wrench 1
23A 106582 I.D. Shim 2
24 R-10042 Main Shaft Key to Eccentric 2
25 R-10039 Main Shaft Key-Lower 1
26 R-10035 Hammer Pin 1
27 R-10066 Urethane plug 1
28 108184 Name Plate 1
29 R-10033 Tie-Rod 2
30 R-30018 Motor Adapter 1
31 ZA11167 Grommet 2
32 R-10030 Lift Rod Coupling(2.50” Long) 1
33 R-40011 Pedestal Cover 1
33A 8/18 X 75 Self Tapping Screw 1
34 R-10061 Flange Bearing 1
35 R-10062 Bearing 1
36 R-10063 Flange Bearing 2
37 ZF10168 Thrust Washer 1
38 R-10065 Steel Bushing 1
39 ZF10174 3.8-16 NC X 2.25” Carriage Bolt 3
40 R-10070 Sprocket-14-Teeth (1800 RPM)
w/Set Screw
Sprocket-17-Teeth (1500 RPM)
w/Set Screw
1
1
41 R-40029 Electronic Timer (115v) 1
*ITEMS NOT SHOWN
*PARTS SOLD AS EACH
