Tyler Ro-Tap RX-29-E - Page 8

7
RX-94 Ro-Tap
®
II PARTS LIST
ITEM PART DESCRIPTION QTY
REQD
ITE
M
PART DESCRIPTION QTY
REQD
1 R-40023 Painted Base Weldment 1 48A 106582 ½” I.D. Shim 2
2 ZA11167 Grommet 4 49 ZF10222 ½”-13 Locknut 1
3 R-10117 Gasket Channel 4 50 R-10036 Lift Rod 2
4 R-10061 Flanged Bearing 1 51 R-10030 Lift Rod Coupling 1
5 R-10062 Bearing 1 52 ZF10251 5/16-24 x 1/25” Long Socket
Head Cap Screw
1
6 R-20027 Mainshaft 1 53 R-30015 Timing Belt Pulley 1
7 R-10055 Shim 1.42O.D. x .0155 Th. 1 54 ZF10271 3/8 I.D. X 1.50” O.D. Fender
Washer
1
8 R-10034 Eccentric Disc 2 55 R-10039 Main Shaft Key (Lower) 1
9 R-10042 Main Shaft Key 2 56 R-10058 Timing Belt 1
10 ZF10174 3/8-16 x 2.25” Carriage Bolt 3 57 R-40011 Pedestal Cover 1
11 R-10032 Block 1 58 R-40020 Dual Sieve Cover 1
12 R-10065 Steel Bushing .62 O>D> x .385 I.D.
x1.25”
1 59 R-40030 Timer Enclosure 1
13 ZF10168 3/8” Flatwasher 1 60* R-40029 Electronic Timer (115v) 1
14 ZF10221 3/8-16 Locknut 2 60* R-40037 Electronic Timer (230v) 1
15 R-40017 Lower Carrying Plate 1 61* ZZ10014 ¼ x 1.25” Long Hex Head
Screw
2
16 R-10028 Tube Spacer 2 62* ZZ10281 ¼ I.D. Flat Washer 2
17 R-20020 Bearing Plate 1 63* R-40034 Spacer (for Timer Enclos.) 2
18 R-20019 Back-Up Plate 1 64* ZZ10253 ¼-20 Hex Nut 2
19 ZF10221 3/8-16 Lockout 2 65 108184 Name Plate 1
20 R-40019 Upper Carrying Plate 1 66 Std.#7 Drive Screws 2
21 R-30006 Support Plate 2 67 R-10118 3 ¼” Octagon Box (Appleton
#30))
1
22 R-40018 Dual Sieve Support Clamp Bar 1 68* R-40032 3 ¼” Square Box Cover 1
23 R-40021 Tie Rod 2 69 R-10119 ½” Cord Grip Strain Relief
(Appleton #CG31505)
1
24 R-10079 Clamp Screw 2 70* 11478 X 1/50 Long Nipple 1
25 R-20033 Shield 2 72 R-10112 Straight Connector?APC-050 2
26 ZF10241 3/8-16 x .75” Long Flat Head Screw 4 73* R-10116 Extra Flex Connector/ APC-0509 2
27 ZF10231 #10-32 x .50” Long Flat Head Screw 6 74* 114163 Non-Metallic Flex Conduit (LTC
050) 0’ 12” Long
1
28 R-20082 Adj. Handles (Support Bar) 2 75* 114164 Non Metallic Flex Conduit
(LTC050) 1’ 9 ½” Long
1
29 R-10066-A Urethane Plug 1 76 R-40028 Hand Retractable Plunger 2
30 R-30010 Rotating Guard Assembly 1 77 R-10099-30 Gas Spring (Guden #CG824-30) 1
78 114165 Spring Stud (Guden #BS101-02) 2
31 R-30019 Sheet Guard 1
32 R-10038 Upper Mainshaft Washer 1
33 114162 3/8-16 x .62” Long Hex Head Cap
Screw
2
34 R-20029 8” Hammer 1
35 R-20023 Hammer Block 1
36 R-10063 Flanged Bearing 2
37 R-10035 Hammer Pin 1
38 ZA10148 #10-24 x .25” Long Flat Point Socket
Screw
1
39 ZZ10068 1/2 x 2.50” Long Hex Head Bolt 1
40 ZZ10323 ½ I.D. Lockwasher 1
42 P-1500-23 Motor-Standard 115/230V 60/50Hz 1
phase
1
43 R-30018 Motor Adapter Plate 1
44 R-10070 Sprocket-14 Teeth(1800 rpm) w/ Set
Screw
1
45 ZF10183 3/8-16 x 1.00” Long Hex Head Screw 4
46 ZF10168 3/8 I.D. Flat Washer 4
47 R-20039 Cam Gear 1
48 R-10029 Cam Shoulder Screw 1
*ITEMS NOT SHOWN
*PARTS SOLD AS EACH
