So that the steam generator's automatic emptying and
rinsing functions are not rendered inoperative (which
may reduce the life of the generator), it is essential that
there is always a current in the power feed cable X. An
exception may, of course, be made when servicing the
steam generator.
The steam generator is always switched on and off from
the control panel or some other switch, timeclock etc.
which is connected to the cable marked Z.
ABkW
6-12 224 570
2
3
H
D
E
Y
F
G
Z
V
X
1
5
4
3
2
1700mm
1a
1b
Max 3m
90
485
A
B
70
415
10
130
445
Min. 500
Min. 500
