BLADE INSTALLATION
When reinstalling the blade note ori-
entation, the "wing" must be point-
ing upward the top of the deck.
► BELT REPLACEMENT
The mower deck belts should be
replaced every 200 hours of mower
operation, or anytime the belts
shows sign of wear, cracking, or
other damage.
Remove hardware securing the Left/
Right Hand Belt cover to the deck.
►
The Idler Arm with Idler Pulley are
under spring tension. To prevent
possible injury, use caution when
handling the Idler Arm assmbly.
CAUTION
Place a "Breaker Bar" in the square
hole provided in the Idler Arm. Care-
fully push the Idler Arm towards the
left hand side, away from discharge
opening to relieve tension from the
belt. Slip the belt off of the Right
hand Spindle Pulley, then carefully
release the Idler Arm.
Remove the belt from the Center
Spindle Pulley.
Remove the belt from the rst xed
Idler Pulley.
Remove the belt from the Left Hand
Spindle Pulley.
Remove the belt from the Idler Arm
Pulley.
Remove the belt from the Gear Box
Pulley.
Remove the belt from the Second
Idler Pulley.
Remove the belt from the deck and
discard.
