BELT REPLACEMENT
Route the "backside" of the belt
around the fixed Idler Pulley near
Gear Box.
Route belt around Gear Box Pulley
Route the belt around the Idler Arm
Pulley. The "backside" of the belt
will be marking contact with the Arm
Pulley.
Route belt around the Left Hand
Spindle Pulley.
Route the "backside" of the belt
around the fixed Idler Pulley near
Center Spindle.
Route belt around the Center Spin-
dle Pulley.
Make certain the belt is properly
engaged in each pulley, then place
a " Breaker Bar" in the square hole
provided in the Idler Arm. Carefully
push the Idler Arm towards the left
hand side, away from discharge
opening the relieve tension. Slip the
►
belt over the Right Hand Spindle
Pulley, then carefully release the
Idler Arm.
Reinstall Right Hand and Left Hand
Belt covers to the deck
GEAR BOX►
Prior to operation, make sure
the gear box contains the cor-
rect amount of oil If under filled
or overlled, damage to the gear
box or personnel injury may re-
sult.
CAUTION
The lub ric an t lev el sho uld b e
checked each 24 hours of operation.
After the first intial 50 hours of op-
eration, drain the oil and rell to the
proper level, Thereafter, oil changes
should take place after every 250
hours of operation.
Removed plug located on side of
gear box located on the side oppo-
site of the xed Indler Pulley
Correct oil level is to the center line
of the drive shaft
