② Tacho Meter
This meter shows the revolutions of the engine and the PTO shafts as well as the travel
speed in top gear.
③ Hour Meter
The hour meter consists of digits with the last digit indicating 1/10th of an hour.
It shows hours the tractor has been used.
The lamp at bottom of hour meter should twinkle during operation.
④ Fuel Gauge
Shows the amount of fuel in the fuel tank when the key switch is ON.
⑤ Light Switch, Indicators and Horn.
Head lamp is operated on the main switch.
When indicator is pulled down, left turn signal turns ON and flash.
When indicator is pushed up, right turn signal turns ON and flash.
When the horn button is pressed, the horn will sound.
DESCRIPTION OF OPERATING SYSTEM
3
3-3
