SWITCHES AND GAUGES
1. INSTRUMENT PANEL AND CONTROLS
DESCRIPTION OF OPERATING SYSTEM
3-2
① KEY SWITCH
『OFF』 ― The key can be inserted or removed.
『ON』 ― The electric circuit is on.
『GLOW』 ― Glow plugs pre-heat the combustion chamber.
『START』 ― The starter motor is engaged.
When the key is released it will automatically return to the『ON』position.
Right Turn Signal Lamp
Fuel Gauge
Coolant Temperature Gauge
PTO Switch
Cruise Control Switch
Key Switch
Left Turn Signal Lamp
Tachometer
Combination Switch
(Turn Signal Switch,
Head Lamp Switch,
Horn)
Hazard Warning Switch
