② Tachometer
This meter shows the revolutions of the engine and the PTO shafts as well as the travel
speed in top gear.
③ Hourmeter
The hour meter consists of digits with the last digit indicating 1/10th of an hour.
It shows hours the tractor has been used.
The lamp at bottom of hour meter should twinkle during operation.
④ Fuel Gauge
Shows the amount of fuel in the fuel tank when the key switch is ON.
⑤ Coolant Temperature Gauge
The gauge shows the coolant temperature with the key switch ON.
C indicates low to normal temperature and H indicates high temperature.
If the pointer is in the red H segment, the engine is overheating.
DESCRIPTION OF OPERATING SYSTEM
3
3-3
