■ 4WD Lever (Front Wheel Drive Lever)
4WD shift lever is located below the LHS of the operator.
In the ON position the front wheels are engaged and in the OFF position they are
disengaged.
Engage or disengage the front wheel drive with the front wheels in the straight position
and at low speed.
The use of front wheel drive improves traction performance.
IMPORTANT
Do not use front wheel drive at high speed or on the road as premature wear of components will result.
■ Differential Lock Pedal
The differential lock pedal is located below the LHS of the seat.
In case of wheel slippage use the diff-lock by pushing down on the diff lock pedal.
To release it, remove the foot from the pedal.
DESCRIPTION OF OPERATING SYSTEM
Differential Lock Pedal
4WD Lever
