3-10
DESCRIPTION OF OPERATING SYSTEM
■ Sub Shift Lever (Range Shift Lever)
The sub shift lever provides two speed ranges L and H.
The tractor should be stopped before changing speed ranges.
Choose L, H speed range on range shift lever to match work application.
IMPORTANT
Avoid damage!
Select the proper speed range and gear.
• The machine maybe operated in any gear with engine speeds at 1,350-3,000 rpm. Within these limits, the
engine can be placed under varying load operations.
• Never overload the engine by lugging machine at low idle speeds.
• Raise the engine speed to match expected loads. If a slight increase in engine rpm occurs simultaneously
while moving the hand throttle lever forward, the engine is not overloaded.
Sub Shift Lever
