AIR CLEANER
■ Squeezing Dust
To remove the dust from the evacuator valve squeeze it
between thumb and fingers to let excess dust out and wipe
around the valve to keep it clean from outside.
■ Cleaning the Element
1. Open the hood.
2. Remove the element by unlocking the clamp.
3. Remove dust by blowing it out of the
element with compressed air.
4. Check the element to ensure it is not
damaged.
5. Reassemble the element.
IMPORTANT
Never beat the element on a stone or concrete floor/wall to clean it Check all connections and hoses
especially on the clean side of the air cleaner to ensure no dusty air can enter the engine.
Check the element for flaws by putting a light inside the element.
When reassembling make sure all surfaces seal correctly to keep dust out.
When working in dusty conditions increase the service frequency.
▶ Replace the element after cleaning it 5 times or it is damaged.
MAINTENANCE AND SERVICE
5-6
