TYM T433 User Manual

SPECIFICATIONS
Model: T433/T503/T553
ENGINE
Four strokes, Indirect injection, water-cooled
Diesel Engine.
Model : 404C-22(C2.2)
No. of cylinders : 4
Displacement : 2,216 Liters
Bore : 84mm (3.3 in)
Stroke : 100mm (3.9 in)
Compression Ratio : 22.4:1
Rated power (PS) : T433 - 42/2600 rpm
T503 - 50/2800 rpm
T553 – 54/2600 rpm
(Manufacturing rating)
Rated Speed : 2800 rpm
High idle rpm : 3,000±15 RPM
Low idle rpm : 800 ~ 1400 RPM
Fuel injection pump : BOSCH.
Cylinder sleeve : -
Air Cleaner : Dry Filter element,
paper element filtering type.
CLUTCH
Type : Diaphragm
Outer dia. X Inner dia. : Ф260XФ180
TRANSMISSION
Type : synchro mesh
No. of gears :16 forward,
16 reverse speeds
with high and low
selection lever with
Differential Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
Diameter : 1⅜ in.(35mm)
Standard PTO : ①540 ②1000 (Optional)
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation. A foot
93
paper element filtering type.
Exhaust Muffler : Horizontal External type
Firing order : 1-3-4-2
Accelerator : Hand & Foot Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt 80AH
Starter : Solenoid Engaged.
Key Start with interlock,
Neutral switch
Alternator : 12V 65A
Instrumentation : Water Temperature Gauge,
Taco meter, Hour meter,
Electrical fuel level gauge.
Lighting: Head lamps, side indicators,
Rear parking brake
& indicator light
On dash board indicators
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter :Φ183mm(Φin)
Number of lining :4 each side
Total brake thickness : 21.1㎜(in.)
HYDRAULIC SYSTEM
Independent fully”Live”hydraulic pump
and separate reservoir.Position controls with
isolating & response control
Piston and cylinder Lift 1503 kgf
(at lower link top end)
Pump output :
Main : 19.0 cc/rev (46.4 ℓ/min)
Power Steering : 10.0 cc/rev (24.4 ℓ/min)
Delivery(91% efficiency) : liter(cu.in)mm at
2600rpm
3 point linkage : USA -Category 1
EU-Category 2
adjustable outside stabilizer
