► MAIN SPECIFICATIONS
MODEL T433/T503/T553
Engine Maker CATERPILLAR
Model 404C-22(C2.2)
Type
Water cooled 4 cycle 4 cylinder diesel turbo
charged
Out put (ps/rpm)
T433 - 42/2600 rpm
T503 - 50/2800 rpm
T553 - 54/2600 rpm
Number of Cylinder 4
Displacement(cc) 2,219
Bore and Stroke 84X100 mm
Compression ratio 23.3:1
Firing order 1-3-4-2
Injection pump Direct
Lubrication type Forced circulation
Cooling system Water cooled,Forced circulation
94
Coolant capacity 9.8ℓ
Air cleaner Dry Single Element
Muffler Horizontal / side
Fuel Diesel fuel
Fuel Tank capacity 60ℓ(15.85 US gal)
Electrical Battery 12V80AH
Starting system Starter motor with pre-heater
Starter Capacity 2.0KW
Drive Train
Alternator 12V 65A
Transmission
Constant mesh(Synchromeshed 3
rd
and 4
th
in
main shift in both forward and reverse)
MFWD(4WD) Standard
Differential lock Bevel gears with diff-Lock
Brakes Wet disc,mechanical
Steering hydraulic
