-15-
28
1
2
3
1
2
1
5
4
4
A
30.Clean (Fig. 28)
1.Raise the presser foot;
2.Remove the two screws ① and needle plate ②;
3.Clean the feed dog with a soft brush;
4.Install the needle plate ② by two screws ①.
5.Turn the machine pulley slowly and check if the
needle drops into the hole center of needle plate
★If not
●Check if the needle is bent
●Loosen the screw ①, and reinstall the needle
plate ②
6.Turn the machine pulley and lift the needle
above the needle plate, check if the needle tip is
blunt, if yes, change a new one.
7.Tilt back the machine head
8.Remove the bobbin case ④
9.Clean the hook with a soft cloth and check if
the hook is worn out
10.Take out the bobbin from the bobbin case,
and clean the bobbin case with a soft cloth
11.Insert the bobbin into the bobbin case and
place the bobbin case back into the machine
12.Clean the dust on the filter (A) of oil pump.
To Next Page
