u-blox SARA-G3 Series - Page 205

SARA-G3 series - System Integration Manual
UBX-13000995 - R06 Objective Specification Appendix
Page 205 of 218
Pin Name
N°
SARA-G3 series
N°
LISA-C2 series
LISA-U1 series
LISA-U2 series
I2S1_RXD
Not Available
39
Not Available
Not Available
1.8 V, Clock In/Out
Configurable frequency
Inner pull-down: 150
µA
Driver strength: 1 mA
LISA-U200-00S: N.A.
Other
CODEC_CLK
Not Available
52
Not Available
Not Available
1.8 V, 13/26 MHz Out
Driver strength: 4 mA
LISA-U200-00S: N.A.
GPIO
GPIO1
16
SARA-G350 only:
1.8 V, configurable GPIO
Default: Pad disabled
Driver strength: 6 mA
Inner pull-down: 51 µA
20
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 4 mA
Inner pull-down: 30 µA
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 1 mA
Inner pull-down: 100
µA
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO2
23
SARA-G350 only:
1.8 V, configurable GPIO
Default: GNSS supply ena.
Driver strength: 6 mA
Inner pull-down: 51 µA
21
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 4 mA
Inner pull-down: 30 µA
1.8 V, configurable
GPIO
Default: GNSS supply
en.
Driver strength: 1 mA
Inner pull-down: 85 µA
1.8 V, configurable
GPIO
Default: GNSS supply
en.
Driver strength: 1 mA
Inner pull-down: 150
µA
GPIO3
24
SARA-G350 only:
1.8 V, configurable GPIO
Default: GNSS data ready
Driver strength: 5 mA
Inner pull-down: 27 µA
23
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 4 mA
Inner pull-down: 30 µA
1.8 V, configurable
GPIO
Default: GNSS data
ready
Driver strength: 4 mA
Inner pull-down: 55 µA
1.8 V, configurable
GPIO
Default: GNSS data
ready
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO4
25
SARA-G350 only:
1.8 V, configurable GPIO
Default: GNSS RTC shar.
Driver strength: 6 mA
Inner pull-down: 51 µA
24
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 4 mA
Inner pull-down: 30 µA
1.8 V, configurable
GPIO
Default: GNSS RTC
sharing (4.7 k external
pull-down required for
RTC sharing)
Driver strength: 4 mA
Inner pull-down: 55 µA
1.8 V, configurable
GPIO
Default: GNSS RTC
sharing
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO5
Not Available
51
1.8 V, configurable
GPIO
Default: Pad disabled
Driver strength: 4 mA
Inner pull-down: 30 µA
1.8 V, configurable
GPIO
Default: SIM detection
Driver strength: 2.5 mA
Inner pull-down: 55 µA
1.8 V, configurable
GPIO
Default: SIM detection
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO6
Not Available
39
Not Available
Not Available
1.8 V, configurable
GPIO
Default: I2S1_RXD
Driver strength: 1 mA
Inner pull-down: 150
µA
