u-blox SARA-G3 Series User Manual

SARA-G3 series - System Integration Manual
UBX-13000995 - R06 Objective Specification Appendix
Page 206 of 218
Pin Name
N°
SARA-G3 series
N°
LISA-C2 series
LISA-U1 series
LISA-U2 series
GPIO7
Not Available
40
Not Available
Not Available
1.8 V, configurable
GPIO
Default: I2S1_TXD
Driver strength: 1 mA
Inner pull-down: 150
µA
GPIO8
Not Available
53
Not Available
Not Available
1.8 V, configurable
GPIO
Default: I2S1_CLK
Driver strength: 1 mA
Inner pull-down: 150
µA
GPIO9
Not Available
54
Not Available
Not Available
1.8 V, configurable
GPIO
Default: I2S1_WA
Driver strength: 1 mA
Inner pull-down: 150
µA
GPIO10
Not Available
55
Not Available
Not Available
1.8 V, configurable
GPIO
Default: SPI_SCLK
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO11
Not Available
56
Not Available
Not Available
1.8 V, configurable
GPIO
Default: SPI_MOSI
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO12
Not Available
57
Not Available
Not Available
1.8 V, configurable
GPIO
Default: SPI_MISO
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO13
Not Available
58
Not Available
Not Available
1.8 V, configurable
GPIO
Default: SPI_SRDY
Driver strength: 6 mA
Inner pull-down: 200
µA
GPIO14
Not Available
59
Not Available
Not Available
1.8 V, configurable
GPIO
Default: SPI_MRDY
Driver strength: 6 mA
Inner pull-down: 200
µA
