The pin configured to provide the “General purpose output” function is set as
o Output / Low, if the parameter <gpio_out_val> of AT+UGPIOW command is set to 0
o Output / High, if the parameter <gpio_out_val> of AT+UGPIOW command is set to 1
 Pad disabled:
All the GPIOs can be configured in tri-state with an internal active pull-down enabled, as a not used
pin, setting the parameter <gpio_mode> of +UGPIOC AT command to 255.
The “Pad disabled” mode can be provided on more than one pin per time: it is possible to
simultaneously set the same mode on another pin (also on all the GPIOs).
The pin configured to provide the “Pad disabled” function is set as
o Tri-state with an internal active pull-down enabled
Table 11Table 11 describes the configurations of all SARA-G350 GPIO pins.
Pin
Module
Name
Description
Remarks
16
SARA-G350
GPIO1
GPIO
By default, the pin is configured as Pad disabled.
Can be alternatively configured by the AT+UGPIOC command as
 Output
 Input
 Network Status Indication
 GNSS Supply Enable
 GSM Tx Burst Indication
23
SARA-G350
GPIO2
GPIO
By default, the pin is configured to provide GNSS Supply Enable
function.
Can be alternatively configured by the +UGPIOC command as
 Output
 Input
 Network Status Indication
 Pad disabled
24
SARA-G350
GPIO3
GPIO
By default, the pin is configured to provide GNSS Data Ready
function.
Can be alternatively configured by the +UGPIOC command as
 Output
 Input
 Network Status Indication
 GNSS Supply Enable
 Pad disabled
25
SARA-G350
GPIO4
GPIO
By default, the pin is configured to provide GNSS RTC sharing
function.
Can be alternatively configured by the +UGPIOC command as
 Output
 Input
 Network Status Indication
 GNSS Supply Enable
 Pad disabled
Table 11: GPIO pins configurations
