U-Line CLR2060 Installation Guide

CLR2060 — Clear Ice Maker
www.U-LineService.com 2 02/2005
™
Contents
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Door Swing/Clearances Information . . . . . . . . . . . . . . 4
Reversing the Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Other Site Requirements . . . . . . . . . . . . . . . . . . . . . . . . 6
Side-By-Side Installation Instructions . . . . . . . . . . . . . . 6
Custom 1/4'' Door Panel Insert . . . . . . . . . . . . . . . . . . . 7
Full Overlay Door Panel . . . . . . . . . . . . . . . . . . . . . . . . . 8
Checking Door Alignment . . . . . . . . . . . . . . . . . . . . . . 11
Adjusting Door Alignment . . . . . . . . . . . . . . . . . . . . . . 11
Drain Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Water Supply Connection . . . . . . . . . . . . . . . . . . . . . . . 15
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 16
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation of the CLR2060 . . . . . . . . . . . . . . . . . . . . . . 17
Installation Troubleshooting . . . . . . . . . . . . . . . . . . . . . 18
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 19
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
IMPORTANT
PLEASE READ all instructions completely before
attempting to install or operate the unit.
• This unit requires connection to the water supply.
Improper hook-up can result in substantial property
damage! If you are unsure of your ability to safely
connect the water supply to the unit, consult a licensed
plumber for assistance.
• This unit requires connection to a drain. Improper
connection can result in substantial property damage!
If you are unsure of your ability to safely connect the
unit to a drain, consult a licensed plumber for
assistance.
• This unit requires connection to a grounded (three-
prong), polarized receptacle that has been placed by a
qualified electrician in accordance with applicable
electrical codes.
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
DANGER
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
WARNING
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
CAUTION
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
1 Follow Safety Precautions

U-Line CLR2060 Specifications

General

Brand	U-Line
Model	CLR2060
Category	Ice Maker
Language	English
